CFF4P945R30SA

ITEMS

SPEC

UNIT

Center Frequency [fo]

945.0

MHz

Bandwidth [BW]

fo±15 [ 930.0 ~960.0 ]

MHz

Insertion Loss in BW

3.0

dB max

Ripple in BW

0.8

dB max

Return Loss in BW

15.0

dB min

Attenuation

    Absolute  Value

40 dB min.  @fo±  [890.0 &     ]

40.0 dB min.  @fo±  [ 1000.0 &   ]

MHz

Group Delay Variation

ns max

Input Power

2.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
