CFF8P1732F2132R47FA

ITEMS

ANT>>LOW

ANT>>High

UNIT

Center Frequency [fo]

1732.5

2132.5

MHz

Bandwidth [BW]

fo ±23.5 [1709 ~ 1756 ]

fo ±23.5 [2109~2156]

MHz

Insertion Loss in BW

1.6

1.6

dB max

Ripple in BW

0.5

0.5

dB max

Return Loss in BW  R ANT Port

15

15

dB min

VSW Rin BW      R ALL Port

max

Attenuation

   R Absolute Value

   £ Relative  Value

35dBc min @  [2109 ~2156]

35dBc min @  [1709~1756]

MHz

dB min @ fo ± [  ~  ]

dB min @ fo ± [  ~  ]

MHz

dB min @ fo ± [  ~  ]

dB min @ fo ± [  ~  ]

MHz

dB min @ fo ± [  ~  ]

dB min @ fo ± [  ~  ]

MHz

Isolations

dB   min@[   ~    ]

MHz

dB   min@[   ~    ]

MHz

Input Power

3

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
