ITEMS |
SPEC |
UNIT |
Center Frequency [fo] |
1842.5 |
MHz |
Bandwidth [BW] |
fo ±37.5 [1805.5 ~ 1880 ] |
MHz |
Insertion Loss in BW |
2.5 |
dB max |
Ripple in BW |
1.0 |
dB max |
Return Loss in BW |
15.0 |
dB min |
Attenuation R Absolute Value £ Relative Value |
2.0dB min @ fo ±47.5 [ 1795~ 1890] |
MHz |
5.0dB min @ fo ±57.5 [ 1785~ 1900] |
MHz |
|
32dB min @ fo ±140 [ 1702.5~ 1982.5] |
MHz |
|
dB min @ fo ± [ ~ ] |
MHz |
|
Group Delay Variation |
|
ns max |
Input Power |
|
W max. |
In/Out Impedance |
50 Ω |
|
Operation Temperature Range |
-40℃ to +85℃ |
