CFN6P392R05FA

ITEMS

SPEC

UNIT

Center Frequency [fo]

392.5

MHz

Bandwidth [BW]

fo ±2.5 [390.0 ~ 395.0]

MHz

Insertion Loss in BW

4.0

dB max

Ripple in BW

2.0

dB max

Return Loss in BW

10.0

dB min

Attenuation

   RAbsolute Value

   £Relative  Value

40.0 dB min.  @ fo + 167.5 [560.0 ~ 610.0 ]

MHz

40.0 dB min.  @ fo - 7.5 [380.0 ~385.0 ]

MHz

 dB min.  @ fo ±   [     &   ]

MHz

dB min.  @ fo ±   [     &     ]

MHz

Group Delay Variation

ns max

Input Power

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃  to  +85℃
