CFN10P2657N75FA

ITEMS

SPEC

UNIT

Center Frequency [fo]

2657.5

MHz

Bandwidth [BW]

fo ±37.5 [2620.0~2695.0]

MHz

Insertion Loss in BW

3.0

dB max

Ripple in BW

0.5

dB max

Return Loss in BW

15.0

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

 65dB min.  @  fo ±     [ 2550   &    ]

MHz

dB min.  @  fo ±     [      &     ]

MHz

dB  min.  @  fo ±   [      &      ]

MHz

dB  min.  @  fo ±   [      &      ]

MHz

Group Delay Variation

ns max

Input Power

3.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
